Tempest900 2-Channel Operating Manual
Congure Relays for Individual BeltStations
From the BeltStation:
• Press MENU; select “Set Controls,” select “Select Relay.” Note that there are more options under “Set Controls” than t on the screen.
Scroll to the bottom of the screen and scroll one more detent to see the “Select Relay” option. Select one of the relays: Relay 1 thru
Relay 5. When a relay is selected a check mark will be visible beside the selection.
• To activate the relay, a “Relay Button” must be triggered. To select a “Relay Button,” one of the relays must already have been selected.
To select a “Relay Button,” Press MENU, select “Set Controls,” select “Relay Button,” select one of the trigger options.
• If TalkA or Talk B is selected to activate the relay, the relay will remain closed whenever the button is selected for active talk.
• If Ch A or Ch B is selected to activate the relay, the relay will remain closed whenever channel A or B is selected.
• If STAGE, ENTER, or CALL is selected to activate the relay, the relay will remain closed whenever the button is pressed, for as long as
the button is held.
» If STAGE is selected to activate the relay, and if Stage Announce Audio is enabled, and if the Stage Announce Relay is enabled, all
three functions will operate simultaneously.
» If ENTER is selected to activate the relay, and if Wireless ISO is enabled, both functions will operate simultaneously while in
Operational mode. When in Menu mode, ENTER only functions as an Enter button.
» If CALL is selected to activate the relay, and the CALL feature is enabled, both functions will operate simultaneously.
From the BaseStation:
• Select the numbered key 1 through 5 that corresponds to the BeltStation desired. Scroll to and choose “Select Relay.” Select one of
the relays Relay 1 thru Relay 5.
• Press MENU to go up one level back to the menu.
• Scroll to and select “Relay Button;” select an option to trigger the relay.
Since every user will require a custom application, cables for your RELAY connections will require some bench work with a soldering iron.
Use the Transceiver
Choose an optimum location for the Tempest Remote Transceiver and antenna.
Using standard CAT-5 cable, connect the Transceiver to the BaseStation RJ-45 connector labeled TRANSCEIVER.
The “Power” LED on the Transceiver will light if the BaseStation is powering the unit. If the “Power” LED does not illuminate when connections
are made and the BaseStation is ON, the CAT-5 cable may be too long to deliver adequate power to the Transceiver.
When disconnecting a Remote Transceiver while the BaseStation is power on, it is good practice to power your BaseStation off and back on after
the Remote Transceiver has been reconnected.
Local BaseStation whip antenna is disabled when the remote transceiver is connected.
