Setting up a Wireless Network Encrypted Using WPA/WPA2-PSK
Networking requirement
A home wireless network with a certain level of security must be set up through a simply procedure. In this
case, WPA/WPA2 pre-shared key mode is recommended. See the following figure.
Configuration procedure
Assume that the second SSID of the AP, the WPA2-PSK security mode, and AES encryption algorithm are used.
Step 1 Choose Wireless Setting > SSID Settings.
Step 2 Select the second SSID from the SSID drop-down list box.
Step 3 Select the Enable check box.
Step 4 Change the value of the SSID text box to Home.
Step 5 Set Security Mode to WPA2-PSK and Encryption Algorithm to AES.
Step 6 Set Key to 87654321.
Step 7 Click Save.
WiFi password: 87654321
