Tenda 11AC User Manual

76
Parameter
Description
If the QVLAN function is enabled, at least one LAN port needs to be set as a trunk port.
LAN0 indicates the LAN port at the rear of the AP (PoE power supply, data transmission multiplexing
port), whereas LAN1 indicates the LAN port (data transmission port) at the front of the AP.
LAN Port
It specifies the LAN ports of the AP, including LAN0 and LAN1.
VLAN ID
It specifies the VLAN ID corresponding to a LAN port used as an access port. The default value is 1.
2.4 GHz SSID
It specifies the currently enabled SSIDs of the AP at 2.4 GHz band.
5 GHz SSID
It specifies the currently enabled SSIDs of the AP at 5 GHz band.
VLAN ID
It specifies VLAN IDs corresponding to SSIDs. The default value is 1000. After the QVLAN function is
enabled, the wireless ports corresponding to SSIDs functions as access ports. The PVID and VLAN ID
of an access port are the same.
If the QVLAN function is enabled, tagged data received by a port of the AP is forwarded to the other ports of
the VLAN corresponding to the VID in the data, whereas untagged data received by a port of the AP is
forwarded to the other ports of the VLAN corresponding to the PVID of the port that receives the data.
The following table describes how ports of different link types process transmitted and received data.
Port
Method to Process Received Data
Method to Process Transmitted
Data
Tagged Data
Untagged Data
Access
Forward the data to other ports
of the VLAN corresponding to
the VID in the data.
Forward the data to the
other ports of the VLAN
corresponding to the PVID of
the port that receives the
data
Transmit data after removing tags
from the data.
Trunk
If the VID and PVID of a port are
the same, transmit data after
removing tags from the data.
If the VID and PVID of a port are
different, transmit data without
removing tags from the data.
7.7.3 Example of Configuring QVLAN Settings
Networking requirement
A hotel has the following wireless network coverage requirements:
− Guests are connected to VLAN 2 and can access only the internet. Staffs are connected to VLAN 3
and can access only the LAN.
− Managers are connected to VLAN4 and can access both the LAN and the internet.
