18
Parameter description
It specifies the radio band of the WiFi network to be configured.
It specifies the working mode of the AP, including AP mode and Client+AP mode.
It specifies the primary SSID (wireless network name) of the AP.
It specifies the security mode of the wireless network of the AP. Options include: None, WEP,
WPA-PSK, WPA2-PSK, Mixed WPA/WPA2-PSK, WPA, and WPA2.
Clicking the hyperlink navigates you to the elaborated description of the corresponding security
mode.
It specifies the WPA encryption algorithm of the repeated WiFi network. After you select the
upstream WiFi network from the scanned wireless network list, this parameter will be populated
automatically.
Manually enter the WiFi password of the repeated WiFi network.
After the configuration, you can select the SSID on your wireless devices such as smart phones and enter your
wireless network password to connect to the wireless network of the AP and access the internet through the
AP.
4.2.2 Client+AP Mode
Before configuration, ensure that the upstream AP has been connected to the internet.
For two bands bridging scenario, please ensure that you choose the same upstream AP for both the 2.4
GHz and 5 GHz WiFi networks.
Step 1 Choose Quick Setup.
Step 2 Select the radio band from the drop-down list box to be configured, which is 2.4 GHz in this example.
Step 3 Set Working Mode to Client+AP.
Step 4 Click Scan.
