The SNMP agent function of the AP allows an SNMP manager to use the password to read/write
variables in the MIB of the AP.
8.3 Example of Configuring the SNMP Function
Networking requirement
− The AP connects to an NMS over an LAN. This IP address of the AP is 192.168.0.254/24 and the IP
address of the NMS is 192.168.0.212/24.
− The NMS use SNMP V1 or SNMP V2C to monitor and manage the AP.
Configuration procedure
Configuring the AP
Assume that the administrator name is Tom, read community is Tom, and read/write community is Tom123.
Step 1 Log in to the web UI of the AP and choose SNMP.
Step 2 Set SNMP Agent to Enable.
Step 3 Set the SNMP parameters, Administrator, Device Name, Location, Read Community and Read/Write
Community
Step 4 Click Save.
