Tenda AP4 User Manual

7
Name
Description
RAM
Random Access Memory. It specifies the memory usage of this device.
WLAN MAC Address
It specifies the MAC address of the WiFi network of this device.
PoE LAN/LAN Speed
It specifies connection status of LAN port. It includes connection rate and duplex
mode.
LAN IP Address
It specifies the IP address (also called login or management IP address) of this
device. By default, it is 192.168.0.254.
Firmware Version
It specifies the system software version number of this device.
CPU
Central Processing Unit.
It specifies the CPU usage of this device.
LAN MAC Address
It specifies the MAC address of LAN ports of this device.
In WISP or Router mode, the system status is shown as follows:

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
