Tenda AP4 User Manual

78
Name
Description
Enable SSID
It specifies whether to enable the selected WiFi network.
Broadcast SSID
It specifies whether to broadcast the SSID.
When the device broadcasts an SSID, nearby wireless clients can detect the SSID.
When this parameter is set to Disable, the device does not broadcast the SSID and
nearby wireless clients cannot detect the SSID. In this case, you need to enter the
SSID manually on your wireless client if you want to connect to the WiFi network
corresponding to the SSID. This to some extent enhances the security of the WiFi
network.
It is worth noting that after Broadcast SSID is set to Disable, a hacker can still
connect to the corresponding WiFi network if he/she manages to obtain the SSID by
other means.
Network Mode
It specifies the WiFi network mode of this device. The available options include 11a,
11n, and 11 a/n.

11b: It indicates that clients compliant with the IEEE 802.11b protocol can connect
to the WiFi networks of the device.

11g: It indicates that clients compliant with IEEE 802.11g can connect to the WiFi
networks of the device.

11 b/g: It indicates that all clients compliant with the IEEE 802.11b or IEEE 802.11g
protocol can connect to the WiFi networks of the device.

11b/g/n: It indicates that all clients working at 2.4 GHz band and compliant with
the IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n protocols can connect to the
WiFi networks of the device.
Channel
It specifies channel in which this device operates. Auto indicates that this device
automatically changes to a channel rarely used in the ambient environment to
prevent interference.
Transmit Power
It specifies the transmit power of this device.
Higher number indicates wider WiFi coverage. Setting a proper transmit power helps
improve the performance and security of the WiFi network.
Channel Bandwidth
It specifies the bandwidth of the operating channel of a WiFi network. Change the
default setting only when necessary.

20MHz: It indicates that the channel bandwidth of the device is 20 MHz.

40MHz: It indicates that the channel bandwidth of the device is 40 MHz.

Auto: It specifies that the device can switch its channel bandwidth between 20
MHz and 40 MHz based on the ambient environment.
Extension Channel
Available only when the Channel Bandwidth is set to Auto or 40MHz. It specifies an
additional channel used to increase the channel bandwidth.
Transmit Rate
It specifies wireless transmit rate of the device.

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
