Tenda PW201A User Manual

PW201A Wireless N Powerline AP User Guide
11
¾ 1 * WPS button to quickly establish a secure wireless connection.
1.5 Safety Considerations
Observe the following to avoid any potential harm caused from improper
use.
¾ DO NOT expose the Device to flammable , conductive or humid
objects;
¾ Make sure there is no worn-out electric wire and other appliances are
stably placed.
¾ Operate it in a well-ventilated environment.
¾ DO NOT expose the Device to sun shine or other heat sources;
¾ DO NOT expose the Device to corrosive substances (such as acid and
alkali, etc)
¾ Connect the Device to a wall outlet that matches rated power
requirements.
¾ Input voltage fluctuation should be less than 10%.
¾ For optimal result, connect the Device to a regular wall outlet without
any other devices like hair drier, electric iron, fridge or charger
connected to the same outlet.
¾ Read the Quick Installation Guide before using the Device.

Tenda PW201A Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Fast Ethernet
WLAN data transfer rates supported	300 Mbit/s
Certification	FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	94 mm
Width	60 mm
Height	48 mm
