Tenda PW201A User Manual

PW201A Wireless N Powerline AP User Guide
1.3 Interface/Button Overview
Figure 2-2 Interface/Button
Interface
/Button
Description
LAN
RJ45 port: Connect it to a PC or other network
devices using an Ethernet cable.
WPS/RST
One-touch Encryption/Reset Button: Press for 1-3
seconds to perform WPS authentication; press for
6-10 seconds to reset the Device.
PAIR
Pair Button: Press for 1-3 seconds to pair with
other PLC devices; press for 9-10 seconds to
disconnect from the existing network;
9

Tenda PW201A Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Fast Ethernet
WLAN data transfer rates supported	300 Mbit/s
Certification	FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	94 mm
Width	60 mm
Height	48 mm
