Tenda PW201A User Manual

PW201A Wireless N Powerline AP User Guide
Chapter 5 LAN Settings
This section allows you to configure Device’s LAN settings.
¾ IP Address: Device’s LAN IP, namely the management IP. The
default is 192.168.0.254. You can change it according to your need.
¾ Subnet Mask: Device’s LAN subnet mask. The default is
255.255.255.0. You can change it according to your need.
Note:
1. If you change the Device’s LAN IP address, you will need to set IP
addresses of PCs on LAN to the same IP net segment as Device's new IP
address and enter the new IP in your browser to get back to the web-based
configuration utility. 2. If you want to manage the Device while accessing
Internet in the meantime, you will need to set Device's LAN IP to the same
IP net segment as the Internet-enabled router. For example, assuming the
Internet-enabled router is at the IP address of 192.168.1.1, then, you may
set Device's LAN IP address to "192.168.1.254" and set your PC to "Obtain
32

Tenda PW201A Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Fast Ethernet
WLAN data transfer rates supported	300 Mbit/s
Certification	FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	94 mm
Width	60 mm
Height	48 mm
