Tenda PW201A User Manual

PW201A Wireless N Powerline AP User Guide
44
client. When authentication between Device and the intended wireless client
completes, the WPS LED will display a solid light, which indicates the
wireless client has connected to the Device successfully. Repeat steps
mentioned above if you want to connect more wireless clients to the Device.
¾ PIN: To use this option, you must know the wireless client's PIN code
and enter it in the corresponding field on your device while using the
same PIN code on client side for connection.
¾ Reset OOB: When clicked, Device's wireless settings including SSID,
security mode and WPS, etc will be reset to factory default values.
Note:
1. To use the WPS encryption, the wireless adapter must be
WPS-capable.
2. Upon successful WPS connection, the Device's SSID and security
key will change randomly; security mode will change to Mixed
WPA/WPA2-PSK automatically and cipher type will change to TKIP&AES
automatically.
6.5 Connection Status
This section displays the info of connected wireless clients including
MAC addresses and frequency width.

Tenda PW201A Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Fast Ethernet
WLAN data transfer rates supported	300 Mbit/s
Certification	FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	94 mm
Width	60 mm
Height	48 mm
