PW201A Wireless N Powerline AP User Guide
52
1. When adding a repeated MAC address to the PLC Authentication
List, you will be asked whether to update the existing entry.
2. Up to 8 authentication entries can be included.
3. The more authentication entries you add, the longer it takes to
authenticate the Powerline devices, open or refresh the web
page.
4. The PLC authentication feature works only on Tenda Powerline
devices. Authentication on Powerline devices of other brands will fail
whether a correct MAC address and a correct Device Password are
provided or not.
7.3 PLC QoS Settings
QoS prioritizes bandwidth-intensive and latency-sensitive applications
and services such as Internet/IPTV/audio/video/VOIP/online game services,
ensuring high reliability and least latency in transmission of these real-time
data.
The Device provides 4 priority levels: Highest, High, Medium and Low.
It is advisable to assign the highest priority to essential data traffic.
Two QoS priority mapping types are provided: Simple Priority Mapping
and Advanced Priority Mapping.

Tenda PW201A Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Fast Ethernet
WLAN data transfer rates supported	300 Mbit/s
Certification	FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	94 mm
Width	60 mm
Height	48 mm
