Tenda PW201A User Manual

PW201A Wireless N Powerline AP User Guide
3
Table of Contents
COPYRIGHT STATEMENT............................................................ 2
TABLE OF CONTENTS.................................................................. 3
CHAPTER 1 PRODUCT OVERVIEW ............................................. 6
1.1 PACKAGE CONTENTS (FOR REFERENCES ONLY).......................... 6
1.2 LED OVERVIEW....................................................................... 7
1.3 INTERFACE/BUTTON OVERVIEW................................................. 9
1.4 FEATURES............................................................................. 10
1.5 SAFETY CONSIDERATIONS ...................................................... 11
CHAPTER 2 HARDWARE INSTALLATION .................................. 13
2.1 INSTALLATION METHOD........................................................... 13
2.2. INSTALLATION INSTRUCTIONS ................................................. 14
2.3 VERIFY PHYSICAL CONNECTION .............................................. 16
CHAPTER 3 INTERNET CONNECTION SETUP.......................... 17
3.1 CONFIG TCP/IP SETTINGS ON YOUR PC .................................. 17
3.2. LOGIN TO WEB UTILITY.......................................................... 25
3.3 QUICK ENCRYPTION ............................................................... 26

Tenda PW201A Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Fast Ethernet
WLAN data transfer rates supported	300 Mbit/s
Certification	FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	94 mm
Width	60 mm
Height	48 mm
