PW201A Wireless N Powerline AP User Guide
16
4. Simply set all PCs connected to the PW201A to "Obtain an IP
address automatically", and they may be able to access Internet then.
2.3 Verify Physical Connection
Below connections must be verified before moving ahead.
1. Verify Power connection
Power connectivity is confirmed when the Power LED on the Device is
illuminated.
2. Verify Ethernet connection
Ethernet connectivity is confirmed when the LAN LED on the Device is
illuminated. Namely, other network devices (such PC, ADSL Modem or
Router, etc) are connected to the Device.
3. Verify Powerline connection
Powerline connectivity is confirmed when the PLC LED on the Device
is illuminated. Namely, the Device has been successfully connected to
another Powerline device.

Tenda PW201A Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Fast Ethernet
WLAN data transfer rates supported	300 Mbit/s
Certification	FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	94 mm
Width	60 mm
Height	48 mm
