TERASAKI TemBreak 2 - Page 58

5-10
Externally mounted accessories
Series/type of breaker
XMB10
XS2000ND,
XS2500ND
●AC100-110V
●AC200-220V
●DC100-110V
Peak steady-state/
starting current, A ③
AC100-110V
0.85/3.5
AC200-220V 1.3/2.1
DC100V 1.1/2.5
DC110V 1.2/3.0
Operation method
Motordriven
Operating time, s
at rated voltage
2.0
1.6④⑤
Operating switch ratings
250V,5A
Power supply required
300VAorhigher
Dielectric withstand voltage
(for one minute)
AC1000V
Weight
16kg
Rated operational voltage ①
Auto reset
Optional②
Non
XMB12
XS3200ND
●AC100-110V
●AC200-220V
●DC100-110V
Optional②
Non
0.85/3.5
1.3/2.1
1.1/2.5
1.2/3.0
Motordriven
2.0
1.6④⑤
250V,5A
300VAorhigher
AC1000V
16kg
1. Motor operators (MC)
Motor driven type
Ratings and Specifications
Notes: ① Permissible operating range is 85 to 110%.
A power transformer is available as option
for AC380V or AC400-460V.
② Auto reset require to use auxiliary switch
(1b) installed in the breaker. If the number
of auxiliary switches is insufficient, actuate
an external relay via an auxiliary switch (1a)
and use the relay contact (1b) for auto
reset.
③ The currents shown are the maximum
values at the maximum rated operational
voltage.
④ The operating time assume the motor
operator is supplied with the rated
operation voltage. Loss of the motor
operator to fail to work.
⑤ The motor operator is short-time rated. The
number of continuous switching (ON-OFF)
cycles must not exceed 10. After any 10
continuous switching cycles, provide a
pause of at least 15 minutes to the motor
operator for cooling.
(
3
)
XMB
ON-OFF indicator
Operating handle
mounting shaft
ON
OFF/RESET
