TERASAKI TemBreak 2 - Page 73

5-25
5
Accessories
Applicablebreakertypes A① B C Squareshaftapplicable Shaftsupport
Notes:
q. “Min (minimum)” means the minimum possible distance from the panel surface to the breaker mounting surface, which can be formed by cutting the square shaft.
“Max (maximum)” means the maximum distance of the same section, which is formed with no cutting of the square shaft.
w. When dimension A is in a range of 310 mm to 340 mm, cut square shaft T2PS402 to an appropriate length and use the shaft without shaft support.
A: Distance from the panel surface to the breaker mounting surface
B: Length of the tube used to cover the square shaft
C: Length of the square shaft used
D: Distance from the tip of the shaft support to the breaker mounting surface
S800-ND, S1000-ND,
PVS800-NDL, PVS800-NNL,
PVS800-NDH, PVS800-GDH
PVS800-NNH
270 min.
12
107.5
T2PS401
Non
310 max.②
52
147.5
410 max.
80
247.5
510 max.
180
347.5 T2PS403
610 max.
280
447.5 T2PS404
340 min.②
10
177.5
T2PS402
Yes
D
――
――
261
261
261
261
ASL : Arrangement Standard Line
H
L
: Handle Frame Centre Line
C
L
: Handle Centre Line
105
105
B
C
34
1.2-3.2
D
24 51
A
100
105
28
20
12
105
12
20
28
200
150
100
100
150
200
C
L
C
L
C
L
H
L
H
L
H
L
Key for key lock
(optional)
M6 (Nominal size of Allen key applicable: 3)
Shaft support
¡Outline dimensions
¡Panel cutout dimensions
4-ø10
ø110
Handle escutcheon
Panel lock release
• Positions of the hinge and handle as seen
from the load side of the breaker.
Ensure that the hinge is positioned
in the area.
T2HP80
■ Outline dimensions
