Operations Manual United Kingdom 1-October-2013
TA9 & 10 Tier 4 Page 3
Appendices
1 Fuse Box Colour Codes
2 Accessory Socket RD - Red
3 Fuel Pump WH - White
4Beacon YE - Yellow
5 Beacon Switch GN - Green
6 Relay - Fuel Pump BU - Blue
7 Relay - Glow Plug GY - Grey
8 Relay - Ignition OR - Orange
9 Relay - Charge BK - Black
10 Alternator PU - Purple
11 Chassis Earth Point PK - Pink
12 Starter Motor BN - Brown
13 Starter Solenoid
14 Relay - Starter Motor - Fitted to Engine
15 Key Switch
16 Engine Block
17 Battery Isolator
18 Battery 12v
19 Circuit Breaker
