Terex TA10 Operation Manual

Operations Manual United Kingdom 1-October-2013
TA9 & 10 Tier 4 Page 3 - 3
Technical Data 3
3.3 Data
Table 3.4 - Data
Data
TA 9 TA 10
Engine
Manufacturer/Model Deutz TCD3.6 L4
Capacity 3.6 Litre
Rated Power 90kW at 2200 rpm
Maximum Torque 480Nm at 1600 rpm
Oil Capacity 9.0 Litres (2.37 US Gal.)
Cooling System Capacity 14.4 Litres (3.8 US Gal.)
Gearbox
Manufacture/Model ITL SS620
Type Synchro Shuttle
Gears 4 Forward/4 Reverse
Machine Speed in Gears (kph)
1st 5.58
2nd 8.97
3rd 16.61
4th 29.30
Oil Capacity 13.0 Litres (3.4 US Gal)
Transfer Box
Manufacturer/Model ITL
Type TG300
Oil Capacity 0.45 Litres (0.1 US Gal)
Front Axle
Manufacturer/Model DANA
Type 112
Oil Capacity - Axle 7.0 Litres (1.85 US Gal.)
Oil Capacity - Hubs 2.7 Litres (0.71 US Gal.)
Rear Axle
Manufacturer/Model DANA
Type 112
Oil Capacity - Axle 7.0 Litres (1.85 US Gal.)
Oil Capacity - Hubs 2.7 Litres (0.71 US Gal.)
Fuel System
Type Diesel
Tank Capacity 65.0Litres (17.1 US Gal)
Hydraulic System
Tank Capacity 50.0 Litres (13 US Gal)
Pump Casappa PLP20.25S0-0751-HBH/GC-N-2P
Flow 59.8 L/Min (15.7 US Gal/Min)
Working Pressure 172 bar (2494 psi) 210 bar (3045 psi)
