Technical Data 3
1-October-2013 United Kingdom Operations Manual
Page 3 - 4 TA9 & 10 Tier 4
Table 3.4 - Data (Continued)
Data
TA9 TA10
Electrical System
Type 12v Negative Earth
Alternator Belt Driven
Output 95 Amps
Battery Varta Silver 100AH
Braking System
Primary Hydraulic Multi Plate In-board Wet Disc
Parking Mechanical (Disc on output shaft of transmission)
Brake Reservoir 1.20Litres (0.31 US Gallons)
Wheels & Tyres
Manufacturer Starco Starco
Tyre Size 500/60 x 22.5 500/60 x 22.5
Pressure - Front 3.8 bar (55 psi) 3.8 bar (55 psi)
Pressure - Rear 2.2 bar (32 psi) 2.2 bar (32 psi)
Wheel Nut Torque 630Nm (465 ft/lbs)
Skip Capacity
Maximum Safe Payload 9000 kg (19,800 lbs) 10,000 kg (22,000 lbs)
Water - Level
2064 litres (2.7 yd.
3
) 2446 litres (3.2 yd.
3
)
Struck Level
3899 litres (5.1 yd.
3
) 4128 litres (5.4 yd.
3
)
Heaped
4587 litres (6.0 yd.
3
) 5046 litres (6.6 yd.
3
)
