Operations Manual United Kingdom 1-October-2013
TA9& 10 Tier 4 Page 6 - 1
Initial Setup and Adjustments 6
6 Initial Setup and Adjustments
6.1 Delivery Checks
On delivery of the machine:-
• Remove any packaging and shipping supports.
• Release any transport locks.
• Clean any protective coating from bright metal parts.
• Check for damage and missing parts.
• Install battery isolator key.
• Check all fluid levels.
• Check tyres are inflated to correct pressures.
• Check that all manuals/handbooks are present and available to users.
6.2 Setup
Place the ROPS in the work position, Figure 6.1. refers.
Figure 6.1 - ROPS Set Up
1Linch Pin
2 Locking Pin
DANGER
The machine must not be used until the ROPS has been raised and secured in the work
position. It is prohibited to use a machine without the ROPS installed in the work position.
