Description 4
1-October-2013 United Kingdom Operations Manual
Page 4 - 12 TA9 & 10 Tier 4
4.12 Forward/Reverse Switch
This switch, Figure 4.9. refers, permits the machine to be driven in the forward or reverse
direction. The switch has 3 positions:-
0 - Neutral
A - Forward
B - Reverse
Figure 4.9. - Forward/Reverse Switch
1. Forward/Reverse Switch
When the machine is not being used the switch must be returned to the Neutral position to
prevent accidental Movement. If the parking brake is ON and forward or reverse is selected a
buzzer will sound.
4.13 Highway Lighting (When Fitted)
The lighting is controlled by a 3 position switch, Figure 4.10. refers.
Figure 4.10. - Light Switch
1. Lighting Switch.
