Standard Operating Procedures 7
1-June-2014 United Kingdom Operations Manual
Page 7 - 6 TA9 & 10 Tier 4
7.6 To Start the Engine
Before starting the engine check to see that there are no obvious faults with the machine. Refer
to Figure 7.7 for start key positions.
Figure 7.7. - Start Key Positions
1. Start Key Switch
PROCEDURE
1. Sit on the seat.
2. Check that the parking brake is applied and the forward/reverse switch is in Neutral.
3. Check that the gear selector lever is in Neutral
4. Turn the switch to position 1, Operating voltage. Engine ready for operation If the ambient
temperature is below that predetermined in the engine control system, the preheating
phase begins. The electronic engine control controls and activates the current feed to the
glow plugs.
5. Turn further clockwise against spring pressure to position 2, The engine will start.
6. Release the key immediately the engine starts; the pilot lamps will go out.
7. If the engine fails to start and the error lamp comes on, the electronic engine control has
activated the start lock to protect the engine. The start lock is released by switching off
the system for 30 seconds.
8. Should the engine fail to start after 2 attempts investigate the cause by referring to the
fault table - Section 10 (Troubleshooting).
NOTICE
To start engine after fuel filter replacement refer to Troubleshooting Section - 10 - 4.
Do Not use starting sprays to assist engine starting.
Do Not crank engines for more than 20 seconds - allow 1 minute between starting attempts.
Never engage the starter motor when the engine is running.
