Transportation 5
1-October-2013 United Kingdom Operations Manual
Page 5 - 4 TA9 & 10 Tier 4
5.6 Tie Down
When the machine has been put in an acceptable position on the lorry or trailer it must be
secured in place.
An alternative method of tie down using ropes or straps over the wheels is shown in Figure 5.6.
When using this method nail blocks/chocks at the front, rear and outside of each wheel to prevent
movement.
Figure 5.6 - Alternative Tie Down Method
PROCEDURE
1 Place the machine in a suitable position.
2 Apply the parking brake.
3 Fit the articulation lock.
4 Remove battery isolator key.
5 Lower ROPS to transport position.
6 Nail blocks/chocks at the front, rear and outside of each wheel.
7 Tie down using tie down points provided with suitable chains straps or ropes.
8 Loose ends of chains, straps or ropes must be secured to the lorry/trailer bed.
