Description 4
1-October-2013 United Kingdom Operations Manual
Page 4 - 14 TA9 & 10 Tier 4
2. Indicator
3. Side Light
(4) Rear Light Unit
Each rear light unit contains a rear light, brake light, indicator and reflector. Figure 4.13. refers.
Figure 4.13. - Rear Light Unit
1. Indicator
2. Reflector
3. Tail Light
4. Brake Light
(5) Registration Plate Lights
Separate light units that operate in conjunction with the side an tail lights illuminate the rear
registration plate.
4.14 Obstruction Beacon
The beacon is provided to warn people of the machines presence, Figure 4.14. refers. A
mounting for the beacon is located on the ROPS. The beacon is controlled by a switch.
Figure 4.14. - Obstruction Beacon
