Operations Manual United Kingdom 1-October-2013
TA9 & 10 Tier 4 Page 4 - 11
Description 4
4.10 Hour Meter
The hour meter is fitted to the rear face of the dash box - Figure 4.7. refers.
Figure 4.7. - Hour Meter
1. Hour Meter
The hour meter records the total time the engine has been running and is useful for determining
service times for the machine.
4.11 Engine Start/Stop Switch
This switch is located on the side of the dash box, Figure 4.8. refers permits the starting and
stopping of the engine. It has a removable key for security. With the key removed a weatherproof
cover protects the switch from damage.
Figure 4.8. - Start/Stop Switch
