Terex TA10 Operation Manual

Maintenance 9
1-October-2013 United Kingdom Operations Manual
Page 9 - 18 TA9 & 10 Tier 4
(7) Engine Coolant
Shell Glycoshell Antifreeze/Water Mixture
Table 9.3. - Antifreeze Concentrations
(8) Fuel System
Diesel to Specification:-
DIN 51628
EN 590
ASTM D 975 Grade 1-D S15
ASTM D 975 Grade 2-D S15
(9) Grease
Centre Pivot:-
Starplex All Purpose Grease EP2 - Lithium Complex Grease - Gr Lic, NLGI 2
Other Grease Points:-
Multi Purpose Grease EP2 - Lithium Grease Gr Li, NLGI 2
9.17 Fluid Capacities
Table 9.4. - Fluid Capacities
Concentration Ratio Protection ºC Protection ºF
20% 1:5 - 9 15.8
25% 1:4 - 12 10.4
33.3% 1:3 - 19 - 2.2
50% 11:1 - 37 - 34.6
Capacities - Litres
Engine
Sump
Gearbox Transfer
Box
Front
Axle inc
hubs
Rear
Axle inc
hubs
Fuel
Tank
Hydraulic
Tank
Brake
System
Cooling
System
9.0 13.0 0.9 9.7 9.7 67.0 50.0 0.2 14.4
