3 Technical Data
TC29
20
Knickmatik
®
Right: Swing angle 60°
Left: Swing angle 60°
Parallel lateral adjustment at full digging depth,
total 1,040 mm
to the right 595 mm
to the left 445 mm
Dozer blade Independent from drive, sensitive control by means
of hand lever.
Short version
*
Long version
Width 1,410 mm 1,410 mm
Height 325 mm 325 mm
Lift below road level 285 mm 296 mm
Lift above road level 206 mm 406 mm
Slope angle 22° 28°
Slope balance 9.0° 8.0°
*virtually full digging
depth can be achieved
even when articulated
3.8 Lubricants
3.8.1 Filling quantities
The level marking is always the decisive factor.
Diesel fuel approx. ltr. 52.0 Diesel
Engine oil, engine and filter approx. ltr. 7.9 + 0.5
High pressure oil (change
quantity)
Hydraulic oil: Tank approx. ltr. 72.0 Hydraulic oil (change quantity)
Hydraulic oil: Total system approx. ltr. 85.0 Hydraulic oil
Crawler gear units each approx. 0.6 transmission oil
Swing gear circulation lubrication provided by hydraulic system
Coolant approx. ltr. 5.3
water with anti-corrosion agent
and antifreeze *
* The ratio of mixture must be adjusted to the level of antifreeze required.
All values stated are approximate.
