Terex TC29 User Manual

3 Technical Data
TC29
24
3.12 Carrying capacity
The stated carrying capacities in tons (t) were determined in compliance with ISO 10567 and include a
stability factor of 1.33, or 87% of the hydraulic lifting load capacity.
The dead-weight of the work attachment must be deducted from the stated carrying capacity!
Table of carrying capacity with the following equipment:
• including quick-mount hitch
• without bucket
• rubber crawler chain, 300 mm wide
• full tank, with driver
Working envelope for grab, see Chapter 3.11
• with dipperstick 1,350 mm
A = supported by blade V = travelling
Load radius from center of ring gear in m
2.0 2.5 3.0 3.5 4.0
along* across* along* across* along* across* along* across* along* across*
2
A -- -- 0.83 0.68 0.78 0.54 0.66 0.39 -- --
V -- -- 0.68 0.66 0.53 0.53 0.38 0.38 -- --
1
A 1.41 0.94 1.04 0.67 0.91 0.51 0.77 0.38 0.54 0.32
V 0.85 0.93 0.67 0.66 0.45 0.49 0.36 0.37 0.30 0.31
0
A 1.35 0.81 0.98 0.58 0.75 0.48 0.62 0.37 0.52 0.32
V 0.76 0.78 0.56 0.57 0.45 0.46 0.35 0.36 0.29 0.30
-1.0
A 1.04 0.88 0.85 0.52 0.68 0.46 0.45 0.37 -- --
Bucket hinge height
in m
V 0.75 0.82 0.50 0.51 0.43 0.45 0.35 0.36 -- --
• with dipperstick, 1,550 mm
A = supported by blade V = travelling
Load radius from center of ring gear in m
2.0 2.5 3.0 3.5 4.0
along* across* along* across* along* across* along* across* along* across*
2
A -- -- 0.83 0.68 0.78 0.54 0.65 0.38 -- --
V -- -- 0.68 0.66 0.53 0.53 0.37 0.37 -- --
1
A 1.41 0.94 1.04 0.67 0.91 0.51 0.76 0.37 0.52 0.30
V 0.85 0.93 0.67 0.66 0.45 0.49 0.35 0.36 0.28 0.29
0
A 1.35 0.81 0.98 0.58 0.75 0.48 0.61 0.36 0.50 0.30
V 0.76 0.78 0.56 0.57 0.45 0.46 0.34 0.35 0.27 0.28
-1.0
A 1.04 0.88 0.85 0.52 0.68 0.46 0.44 0.36 -- --
Bucket hinge height
in m
V 0.75 0.82 0.50 0.51 0.43 0.45 0.34 0.35 -- --
