6 Recovery and Transport
TC29
50
6.3 Transport of the machine
• When transporting the machine on trucks,
flatbed trailers, or by rail, it must be properly
lashed at the marked points (undercarriage
35/1 and dozer blade 35/2) and secured with
chocks.
• To do so, lower the dozer blade and position
the work equipment on the ground.
Be aware of the total transport height.
Risk of accident when driving in
tunnels, under bridges, etc.!
Loading the machine onto a truck
• The machine can be loaded using ramps with
an angle of up to 15°.
• Secure the vehicle to be loaded with wedges to
prevent it rolling away.
• Drive the machine in reverse onto the vehicle
and drive it forward when unloading it from the
truck.
• Lower the dozer blade and place the working
equipment on the ground.
• Lash down the machine for transport.
HR1435
2
2
1
1
1
1
Fig. 35-Lashing
HR14-03-36
Fig. 36-Loading onto a truck
