5 Work Operation
TC29
40
5.2 Operation – work function
5.2.1 Operation - working equipment
Danger to life
due to incorrect operation of control
system.
• Before starting work, check whether
the ISO or SAE control system is
activated (option).
• Familiarize yourself with the control
system.
Danger of injury
due to uncontrolled movements of the
machine.
• For special jobs it is also necessary to
lock the uppercarriage by applying a
brake. To do so, press and hold the
button toggle switch (23/14).
• (Option) Select the desired mode of operation
for the working equipment using the lever
(23/13).
A = "ISO" control system
B = "SAE" control system
Fig. 23-Operation
