Introduction 1
TC29
3
1.4 Environmental requirements
Applicable environmental requirements must be
observed for all tasks performed on and with the
machine.
During installation, repair and maintenance tasks,
particular care must be taken that substances that
would damage the environment such as
• Lubricating grease and oil
• Hydraulic oil
• Fuel
• Coolants
• Cleaning fluids containing solvents
are not allowed to come in contact with the soil or
the water system.
These substances must be stored in suitable
containers and must be properly transported,
collected and disposed of.
If the substances listed above do reach the soil,
the leak or outlet must be stopped immediately and
the fluid must be cleaned up with a suitable
absorbent material. If necessary, the soil involved
must be removed. Absorbent materials and
removed soil must be disposed of properly.
Applicable environmental requirements must be
observed.
1.5 Pictograms
The following table explains the meaning of the
pictograms which may be attached to your
machine.
Symbol Description
Danger
On machine:
Caution - Safety distance
In Operating Instructions:
Warning
Attention
Battery charge indicator
Pre-heating
Engine oil pressure
Engine oil level
Coolant temperature
Air filter
Fuel
Hydraulic oil
Hydraulic oil filter clogging
indicator
