Technical Data 3
TC29
23
3.11 Dimensions and weights
Dipper stick mm 1,350
Basic machine with rubber track,
dipper 400 mm, without driver kg 2,690
Basic machine with steel track,
dipper 400 mm, without driver kg 2,780
Total width, undercarriage mm 1,400
Total width, uppercarriage (on rear) mm 1,360
Total length (travel position) mm 3,100
Total length (transport position) mm 4,700
Total height (travel position) mm 3,000
Total height (driver's cab) mm 2,480
Uppercarriage rear radius mm 1,300
Ground clearance mm 270
Drawbar pull 1st gear da N 2,600
2nd gear da N 1,100
Excavator installation
Dimensions apply to machine standing on level ground
With dipper stick mm 1,350 1,550
Digging depth max. 1) mm 2,760 2,960
Lowest dipper hinge point 1) mm 2120 2,320
Maximum possible height 1) mm 4,065 4,190
Discharge height 1) mm 2,835 2,960
Highest dipper hinge point 1) mm 3,475 3,600
Max. reach mm 4,805 4,990
Dipper angle of rotation ° 185 185
Ripping force in accordance with DIN 24086 N 13,600 11,900
Breakout force in accordance with DIN 24086 N 21,300 21,300
1) Dimensions apply to machine standing on level ground, but can be increased by tilting the machine
using the blade.
