1 Introduction
4 TW85
Symbol Description
Hydraulic oil
Hydraulic oil level
Hydraulic oil filter clogging
indicator
Operating mode indicator
Operating hours
Hazard warning system
Direction indicator LT/RT
Light, low beam
High-beam indicator
Working floodlights
Rotating warning beacon
Rear fog lamp
V
R
Travel direction FWD/REV
Travel speed
FAST
Travel speed, SLOW
Driving with accelerator
pedal – apportionable driving
Steering reversal
Working hydraulics shut-off
Engine speed setting
Symbol Description
!
Brake reservoir pressure
control
Parking brake
Pendulum axle locking
Dozer blade
Hydraulic rock breaker
Overload warning device
Lashing points
Suspension points for
loading by crane
First-aid kit
Fire extinguisher
Danger of crushing
Danger of injury
The relevant notes in the
operating instructions should
be observed
Grease gun
Lubricating point
