Terex TW85 - Axles

Technical data 3
TW85 23
Priority valve Priority supply of hydraulic oil to steering.
Steering TW85, TW85S Fully-hydraulic, proportionally jointed front axle, by
means of a steering control device and a steering
cylinder integrated in the axle.
Steering TW85 AL Electrically preselectable steering type
Fully-hydraulic, proportionally jointed front and rear
axle, by means of a steering control device and a
steering cylinder integrated in the axles.
The following steering variants are possible through the
two steerable axles:
Normal steering
Normal steering for driving on roads and normal
production mode. Only the front axle is steered.
Four-wheel steering mode
Steering for reducing turning radius. Both axles steer in
opposition.
4WS “crab steering”
Steering for diagonal lateral shifting. Both axles steer in
the same direction.
Wheel deflection max. 30°
3.7 Axles
Front axle
TW85, TW85 AL
Steering planet drive axle with oscillating suspended
transmission, with 2 multiple disk brakes running in oil
bath in center housing and integrated steering cylinder.
Oscillation ± 5,75°
TW85S
Steering planet drive axle with 2-stage, switchable
oscillating suspended transmission, with 2 multiple disk
brakes running in oil bath in center housing and
integrated steering cylinder.
Oscillation ± 5,75°
Rear axle
TW85, TW85
S
Planet drive axle with 2 multiple disk brakes running in
oil bath in the hub.
TW85 AL
Steering planet drive axle with 2 multiple disk brakes
running in oil bath in center housing and integrated
steering cylinder.
