3 Technical data
28 TW85
A = supported by dozer blade V = movable
• Three-piece articulated boom (TPA)
Load radius from center of ring gear
Height of
hook
3 m 4 m 5 m 6 m 7 m
longt. trans-
verse
longt. trans-
verse
longt. trans-
verse
longt. trans-
verse
longt. trans-
verse
3.0
A -- -- 2.39 1.99 1.67 1.44 1.54 1.00 -- --
m
V -- -- 1.83 1.90 1.31 1.35 0.87 0.94 -- --
1.5
A 3.74 2.85 2.23 1.89 1.91 1.35 1.91 0.97 -- --
m
V 2.59 2.72 1.67 1.79 1.17 1.26 0.84 0.90 -- ---
0
A 4.34 2.80 2.61 1.73 1.98 1.26 1.59 0.95 -- --
m
V 2.37 2.60 1.54 1.64 1.10 1.19 0.80 0.87 -- --
-1.0
A 4.54 2.63 2.81 1.71 2.14 1.22 1.42 0.90 -- --
m
V 2.30 2.49 1.47 1.59 1.06 1.14 0.78 0.85 -- --
• Circular boom (CI)
Load radius from center of ring gear
Height of
hook
3 m 4 m 5 m 6 m 7 m
longt. trans-
verse
longt. trans-
verse
longt. trans-
verse
longt. trans-
verse
longt. trans-
verse
3.0
A 5.5 3.2 3.2 1.9 2.3 1.4 1.9 0.9 -- --
m
V 2.9 3.1 1.6 1.8 1.2 1.3 0.8 0.9 -- --
1.5
A 5.1 2.9 3.8 1.8 2.6 1.3 1.9 0.9 -- --
m
V 2.6 2.7 1.7 1.8 1.1 1.2 0.7 0.9 -- --
0
A 5.8 2.4 2.9 1.7 2.5 1.2 2.0 0.8 -- --
m
V 2.1 2.3 1.5 1.6 0.9 1.1 0.7 0.8 -- --
-1.0
A 5.6 2.3 2.9 1.5 2.0 1.1 1.6 0.8 -- --
m
V 2.0 2.2 1.3 1.5 1.0 1.1 0.7 0.8 -- --
