Operation 4
TW85 35
Legend of fig. 10.2 - Instruments and operation
15 Travel direction preselection –
forward/neutral/reverse
26 RED - battery charge indicator
27 YELLOW - pre-heating monitor
28 RED - engine oil pressure
29 YELLOW - air filter control
30
RED - clogging indicator of hydraulic oil
return filter
31 RED – Hydraulic oil level
32 GREEN - direction indicator
33 BLUE - high beam
34 GREEN- rear axle straight
35 GREEN- front axle straight
36 GREEN - travel direction, reverse
37 GREEN - travel direction, forward
38 RED - parking brake
39 RED-brake accumulator pressure
indicator
40 Overload warning device
41 Coolant temperature
42 Operating-hour meter
43 Fuel-level indicator
44 Light switch
45 Rotating beacon
46 Working floodlights
47 Hazard warning switch
48 Pre-heat/ starter switch
49 Fan switch - heating
50 Option – air conditioner
51 Windshield wiper and washer system
52 Working hydraulics shut-off
53 Rock breaker/auxiliary fitting
54 Overload warning device ON/OFF
55 Activation additional control circuit I –
e.g. turn grab; hammer
56 Horn
57 Key – changeover intermediate
boom/fold
58 Fast - slow
59 Apportionable driving
60 OFF switch - travel motion alarm
61 Front dozer blade
62 Pendulum axle locking
63 Parking brake
64 Travel range and steering type switch
65 High-gear changeover switch
Only press if machine is at standstill
and service brake operated!
If red control lamp in switch lights
up, no gear is engaged (idle). The
switchable transmission is in an
intermediate position. The machine
is not ready for driving. This can
be remedied by performing brief
steering movements until the
transmission engages.
66 Indicator – Travel range I
67 Indicator – Travel range II
68 Operation - Additional control circuit II
69 Hydraulic swivel-hold brake
70 Working floodlight, boom
71 Rear fog lamp
72 Option – Steering reversal
73 Option – Change-over "ISO" to "SAE"
control
