7.6.3 Device Type LFG / MFG
Turn on the device by pressing the ‘START’ button. Enter the ‘MAIN
MENU’ by pressing the ‘SELECT’ button. Use the ‘SELECT’ button to
move the arrow and select ‘SERVICE’ from the menu. Press the ‘START’
button (SET) to enter the ‘SERVICE’ menu.
Press ‘SELECT’ button and select by arrow menu point ‘LFG/MFG MODE’
(which specifies Light Weight with 10 kg and Medium Weight for 15 kg
loading device).
Press ‘SELECT’ button and select by arrow menu point ‘LFG/MFG’ mode
(which specifies Light Weight with 10 kg and Medium Weight for 15 kg
loading device).
If the measuring computer is released for operation with MFG, this menu
point is accessible by ‘START’ button (SET).
The display shows the currently selected version by ‘LFG 1.0’ or ‘MFG
2.0’. Press ‘START’ (1.0) or ‘SELECT’ (2.0) to change the version. The safe-
ty prompt appears on the screen, accompanied by voice output ‘Are you
sure?’. Pressing START button (YES) confirms, SELECT button (NO) aborts
the change. After safety prompt, the display shows the currently selected
version.
Press the ‘RESET/OFF’ button (EXIT) to return to the ‘SERVICE’ menu.
Press the ‘RESET/OFF’ button (EXIT) again to return to the ‘MAIN
MENU’. Press the ‘RESET/OFF’ button (EXIT) again to return to the
‘STATUS REQUEST’. Pressing the ‘START’ button will start the test
procedure.
7.6.4 Display Contrast
Turn on the device by pressing the ‘START’ button. Enter the ‘MAIN
MENU’ by pressing the ‘SELECT’ button. Use the ‘SELECT’ button to
move the arrow and select ‘SERVICE’ from the menu. Press the ‘START’
button (SET) to enter the ‘SERVICE’ menu.
Use the ‘SELECT’ button to move the arrow and select ‘DISPLAY
CONTRAST’ from the menu.
Press the ‘START’ button (SET) to enter the ‘CONTRAST’ menu.
The display contrast may be adapted by using the ‘PRINT’ (-) and ‘SELECT’
(+) buttons.
Press the ‘RESET/OFF’ button (EXIT) to return to the ‘SERVICE’ menu.
Press the ‘RESET/OFF’ button (EXIT) again to return to the ‘MAIN
MENU’. Press the ‘RESET/OFF’ button (EXIT) again to return to the
‘STATUS REQUEST’. Pressing the ‘START’ button will start the test
procedure.
SERVICE MENU
INPUTTEST
VERSION
LFG / MFG MODE
DISPLAY CONTRAST
SOUND SERVICE
PRINT DATA
PC-REMOTE
EXIT SET
→
10 / 15 KG MODE MENU
LFG 1.0
EXIT 1.0 2.0
SAFETY QUERY
LFG 1.0
NOW MFG 2.0?
EXIT NO YES
CONTRAST MENU
CONTRAST = 190
EXIT
– +
→
SERVICE MENU
INPUTTEST
VERSION
LFG / MFG MODE
DISPLAY CONTRAST
SOUND SERVICE
PRINT DATA
PC-REMOTE
EXIT SET
→
→
10 / 15 KG MODE MENU
MFG 2.0
EXIT 1.0 2.0
