Settings view
Active menu
Function fields for entering commands
Scroll bar
Selection field for adjustable values:
The selected value is shown with a grey
background. Unavailable values are written in grey
type.
Function keys for entering commands
Measuring view
Active menu, depending on the selected function:
Additional information (e.g. activated fuel, date and
time)
Scroll bar
Display field for readings, parameters
Function keys for entering commands
C.1.4 Instrument connections
Sensor socket
Flue gas socket
Mains unit socket
Pressure socket p+
Pressure socket p-
Gas outlet
C. Product description
