I. Care and maintenance
This chapter describes the steps and action required in order to keep the product func-
tioning properly.
See also
Regular care
, p. 18.
I.1 Cleaning the measuring instrument
If the housing of the instrument is dirty, clean it with a damp cloth. Do not use any
aggressive cleaning agents or solvents. Weak household cleaning agents and soap
suds may be used.
I.2 Replacing sensors
A slot bridge (0192 1552) must be inserted in slots which do not have a sensor. Used
sensors must be disposed of as special waste!
The measuring instrument must be switched off and the mains unit disconnected from
the mains supply.
1
Place the measuring instrument on its front.
2
Loosen screws with a screwdriver, release clip in the direction of the arrow, and
remove service cover.
3
Pull tube connections from the faulty sensor/bridge.
4
Remove the faulty sensor/bridge from the slot.
Do not remove auxiliary circuit boards of the new
sensors until immediately before installation. Do not
leave the sensors without a auxiliary circuit boards
for longer than 15 min.
NO/NO
low
sensors:
Remove the auxiliary circuit board.
5
Insert a new sensor/bridge in the slot.
6
Attach tube connections to the sensor/bridge.
7
Replace and close service cover (clip must click
in), fix with screws.
I. Care and maintanance
46
