TESTO 340 - Printer Configuration

Calling up the function:

Inst’ settings Display edit  .
Setting the display representation:
Select
4 values on disp large or 8 values on disp small  .
Changing parameters and units:
1
Select the display position.
Options:
To insert a space: .
To delete a parameter: .
2
 Select parameter Select unit .
Saving settings:
OK Save input .
F.1.2 Printer
The headers (lines 1-3) and the footer for the printout can be set. The printer that is used
can be activated.
Calling up the function:

Inst’ settings Printer  .
Setting the print text:
1
Print text  .
2
Select
Line 1, Line 2, Line 3 or Footnote  .
3
Enter the values 
OK Save input .
4
Repeat steps
2
and
3
for the other lines in the same way.
5
OK Save input .
Printer selection:
The printer 0554 0543 can only be selected after activating bluetooth, see
Communi-
cation
, p. 30.
Select Printer Select Printer  .
OKOK
OK
OK
Change
OK
OKOK
OK
OKOKChange
Del
Space
OK
OKOK
F. Configuration
28
