AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H OCTOBER 2011REVISED MAY 2015
www.ti.com
Miscellaneous
Miscellaneous/Miscellaneous Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
clkout1 Clock out1 O C15 A15
clkout2 Clock out2 O B15 D14
ENZ_KALDO_1P8V Active low enable input for internal I A7 B4
CAP_VDD_RTC voltage regulator
EXT_WAKEUP EXT_WAKEUP input I B5 C5
nNMI External Interrupt to ARM Cortex-A8 core I C17 B18
nRESETIN_OUT Active low Warm Reset I/OD A16 A10
OSC0_IN High frequency oscillator input I W11 V10
OSC0_OUT High frequency oscillator output O W12 U11
OSC1_IN Low frequency (32.768 KHz) Real Time Clock I A6 A6
oscillator input
OSC1_OUT Low frequency (32.768 KHz) Real Time Clock O A5 A4
oscillator output
PMIC_POWER_EN PMIC_POWER_EN output O C7 C6
porz Active low Power on Reset I E15 B15
RTC_PORz Active low RTC reset input I B7 B5
tclkin Timer Clock In I B15 D14
xdma_event_intr0 External DMA Event or Interrupt 0 I C15 A15
xdma_event_intr1 External DMA Event or Interrupt 1 I B15 D14
xdma_event_intr2 External DMA Event or Interrupt 2 I B16, E18, K18 C15, C18, H18
60 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
