AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com SPRS717H –OCTOBER 2011–REVISED MAY 2015
General Purpose IOs/GPIO2 Signals Description (continued)
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
gpio2_3 GPIO I/O W9 T7
gpio2_30 GPIO I/O G19 G17
gpio2_31 GPIO I/O G17 G18
gpio2_4 GPIO I/O U8 U6
gpio2_5 GPIO I/O V8 T6
gpio2_6 GPIO I/O U1 R1
gpio2_7 GPIO I/O U2 R2
gpio2_8 GPIO I/O V1 R3
gpio2_9 GPIO I/O V2 R4
General Purpose IOs/GPIO3 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
gpio3_0 GPIO I/O J19 H16
gpio3_1 GPIO I/O J18 H17
gpio3_10 GPIO I/O M19 L18
gpio3_13 GPIO I/O NA F15
gpio3_14 GPIO I/O NA A13
gpio3_15 GPIO I/O NA B13
gpio3_16 GPIO I/O NA D12
gpio3_17 GPIO I/O NA C12
gpio3_18 GPIO I/O NA B12
gpio3_19 GPIO I/O NA C13
gpio3_2 GPIO I/O K19 J15
gpio3_20 GPIO I/O NA D13
gpio3_21 GPIO I/O NA A14
gpio3_3 GPIO I/O K17 J16
gpio3_4 GPIO I/O L19 J17
gpio3_5 GPIO I/O C18 C17
gpio3_6 GPIO I/O B19 C16
gpio3_7 GPIO I/O A15 C14
gpio3_8 GPIO I/O D14 B14
gpio3_9 GPIO I/O N19 K18
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 59
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
