AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
General Purpose IOs/GPIO1 Signals Description (continued)
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
gpio1_2 GPIO I/O V12 R8
gpio1_20 GPIO I/O NA R14
gpio1_21 GPIO I/O NA V15
gpio1_22 GPIO I/O NA U15
gpio1_23 GPIO I/O NA T15
gpio1_24 GPIO I/O NA V16
gpio1_25 GPIO I/O NA U16
gpio1_26 GPIO I/O NA T16
gpio1_27 GPIO I/O NA V17
gpio1_28 GPIO I/O V18 U18
gpio1_29 GPIO I/O W8 V6
gpio1_3 GPIO I/O W13 T8
gpio1_30 GPIO I/O V14 U9
gpio1_31 GPIO I/O U15 V9
gpio1_4 GPIO I/O V13 U8
gpio1_5 GPIO I/O W14 V8
gpio1_6 GPIO I/O U14 R9
gpio1_7 GPIO I/O W15 T9
gpio1_8 GPIO I/O F19 E18
gpio1_9 GPIO I/O F18 E17
General Purpose IOs/GPIO2 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
gpio2_0 GPIO I/O U17 T13
gpio2_1 GPIO I/O V16 V12
gpio2_10 GPIO I/O W2 T1
gpio2_11 GPIO I/O W3 T2
gpio2_12 GPIO I/O V3 T3
gpio2_13 GPIO I/O U3 T4
gpio2_14 GPIO I/O V4 U1
gpio2_15 GPIO I/O W4 U2
gpio2_16 GPIO I/O U5 U3
gpio2_17 GPIO I/O V5 U4
gpio2_18 GPIO I/O N17 L17
gpio2_19 GPIO I/O N16 L16
gpio2_2 GPIO I/O V10 R7
gpio2_20 GPIO I/O P19 L15
gpio2_21 GPIO I/O P18 M16
gpio2_22 GPIO I/O U7 U5
gpio2_23 GPIO I/O T7 R5
gpio2_24 GPIO I/O W5 V5
gpio2_25 GPIO I/O W7 R6
gpio2_26 GPIO I/O H19 F17
gpio2_27 GPIO I/O H18 F18
gpio2_28 GPIO I/O H17 G15
gpio2_29 GPIO I/O G18 G16
58 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
