AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
General Purpose IOs
General Purpose IOs/GPIO0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
gpio0_0 GPIO I/O P17 M17
gpio0_1 GPIO I/O R19 M18
gpio0_10 GPIO I/O W6 V4
gpio0_11 GPIO I/O V7 T5
gpio0_12 GPIO I/O E17 D18
gpio0_13 GPIO I/O D19 D17
gpio0_14 GPIO I/O D18 D16
gpio0_15 GPIO I/O C19 D15
gpio0_16 GPIO I/O M17 J18
gpio0_17 GPIO I/O N18 K15
gpio0_18 GPIO I/O G16 F16
gpio0_19 GPIO I/O C15 A15
gpio0_2 GPIO I/O A18 A17
gpio0_20 GPIO I/O B15 D14
gpio0_21 GPIO I/O M18 K16
gpio0_22 GPIO I/O V15 U10
gpio0_23 GPIO I/O W16 T10
gpio0_26 GPIO I/O T12 T11
gpio0_27 GPIO I/O U12 U12
gpio0_28 GPIO I/O L18 K17
gpio0_29 GPIO I/O K18 H18
gpio0_3 GPIO I/O B18 B17
gpio0_30 GPIO I/O R15 T17
gpio0_31 GPIO I/O W18 U17
gpio0_4 GPIO I/O B17 B16
gpio0_5 GPIO I/O A17 A16
gpio0_6 GPIO I/O B16 C15
gpio0_7 GPIO I/O E18 C18
gpio0_8 GPIO I/O V6 V2
gpio0_9 GPIO I/O U6 V3
General Purpose IOs/GPIO1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
gpio1_0 GPIO I/O W10 U7
gpio1_1 GPIO I/O V9 V7
gpio1_10 GPIO I/O E19 E15
gpio1_11 GPIO I/O F17 E16
gpio1_12 GPIO I/O U13 T12
gpio1_13 GPIO I/O T13 R12
gpio1_14 GPIO I/O W17 V13
gpio1_15 GPIO I/O V17 U13
gpio1_16 GPIO I/O NA R13
gpio1_17 GPIO I/O NA V14
gpio1_18 GPIO I/O NA U14
gpio1_19 GPIO I/O NA T14
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 57
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
