AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com SPRS717H –OCTOBER 2011–REVISED MAY 2015
eCAP
eCAP/eCAP0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
eCAP0_in_PWM0_out Enhanced Capture 0 input or Auxiliary PWM0 I/O E18 C18
output
eCAP/eCAP1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
eCAP1_in_PWM1_out Enhanced Capture 1 input or Auxiliary PWM1 I/O B16, B19, F17 C15, C16, E16
output
eCAP/eCAP2 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
eCAP2_in_PWM2_out Enhanced Capture 2 input or Auxiliary PWM2 I/O C18, E19 C12, C17, E15
output
