AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H OCTOBER 2011REVISED MAY 2015
www.ti.com
eHRPWM
eHRPWM/eHRPWM0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
ehrpwm0A eHRPWM0 A output. O A18 A13, A17
ehrpwm0B eHRPWM0 B output. O B18 B13, B17
ehrpwm0_synci Sync input to eHRPWM0 module from an I A17 A16, C12
external pin
ehrpwm0_synco Sync Output from eHRPWM0 module to an O U12, V2, W4 R4, U12, U2, V14
external pin
ehrpwm0_tripzone_input eHRPWM0 trip zone input I B17 B16, D12
eHRPWM/eHRPWM1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
ehrpwm1A eHRPWM1 A output. O U5 U14, U3
ehrpwm1B eHRPWM1 B output. O V5 T14, U4
ehrpwm1_tripzone_input eHRPWM1 trip zone input I V4 R13, U1
eHRPWM/eHRPWM2 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
ehrpwm2A eHRPWM2 A output. O U1, V15 R1, U10
ehrpwm2B eHRPWM2 B output. O U2, W16 R2, T10
ehrpwm2_tripzone_input eHRPWM2 trip zone input I T12, V1 R3, T11
62 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
