eQEP
eQEP/eQEP0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
eQEP0A_in eQEP0A quadrature input I M18 B12, K16
eQEP0B_in eQEP0B quadrature input I L18 C13, K17
eQEP0_index eQEP0 index. I/O K17 D13, J16
eQEP0_strobe eQEP0 strobe. I/O P19 A14, L15
eQEP/eQEP1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
eQEP1A_in eQEP1A quadrature input I V6 R14, V2
eQEP1B_in eQEP1B quadrature input I U6 V15, V3
eQEP1_index eQEP1 index. I/O W6 U15, V4
eQEP1_strobe eQEP1 strobe. I/O V7 T15, T5
eQEP/eQEP2 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
eQEP2A_in eQEP2A quadrature input I U13, W2 T1, T12
eQEP2B_in eQEP2B quadrature input I T13, W3 R12, T2
eQEP2_index eQEP2 index. I/O V3, W17 T3, V13
eQEP2_strobe eQEP2 strobe. I/O U3, V17 T4, U13
