Timer
Timer/Timer4 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
timer4 Timer trigger event / PWM out I/O C15, C18, K17, A15, C17, J16,
V10 R7
Timer/Timer5 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
timer5 Timer trigger event / PWM out I/O D19, H19, R19 , D17, F17, M18,
V8 T6
Timer/Timer6 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
timer6 Timer trigger event / PWM out I/O E17, H18, P17, D18, F18, M17,
U8 U6
Timer/Timer7 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
timer7 Timer trigger event / PWM out I/O B15, B19, F19, C16, D14, E18,
W9 T7
