AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
PRU-ICSS
PRU-ICSS/eCAP Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
pr1_ecap0_ecap_capin_apwm_o Enhanced capture input or Auxiliary PWM out I/O E18, V17 C18, U13
PRU-ICSS/ECAT Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
pr1_edc_latch0_in Data In I E17 D18
pr1_edc_latch1_in Data In I D19 D17
pr1_edc_sync0_out Data Out O F19 E18
pr1_edc_sync1_out Data Out O F18 E17
pr1_edio_data_in0 Data In I B17 B16
pr1_edio_data_in1 Data In I A17 A16
pr1_edio_data_in2 Data In I U7 U5
pr1_edio_data_in3 Data In I T7 R5
pr1_edio_data_in4 Data In I W5 V5
pr1_edio_data_in5 Data In I W7 R6
pr1_edio_data_in6 Data In I V14, V3 T3, U9
pr1_edio_data_in7 Data In I U15, U3 T4, V9
pr1_edio_data_out0 Data Out O B17 B16
pr1_edio_data_out1 Data Out O A17 A16
pr1_edio_data_out2 Data Out O U7 U5
pr1_edio_data_out3 Data Out O T7 R5
pr1_edio_data_out4 Data Out O W5 V5
pr1_edio_data_out5 Data Out O W7 R6
pr1_edio_data_out6 Data Out O V14, V3 T3, U9
pr1_edio_data_out7 Data Out O U15, U3 T4, V9
pr1_edio_latch_in Latch In I B18 B17
pr1_edio_sof Start of Frame O A18 A17
PRU-ICSS/MDIO Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
pr1_mdio_data MDIO Data I/O U17 T13
pr1_mdio_mdclk MDIO Clk O V16 V12
PRU-ICSS/MII0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
pr1_mii0_col MII Collision Detect I W16 T10
pr1_mii0_crs MII Carrier Sense I U17, W5 T13, V5
pr1_mii0_rxd0 MII Receive Data bit 0 I V5 U4
pr1_mii0_rxd1 MII Receive Data bit 1 I U5 U3
pr1_mii0_rxd2 MII Receive Data bit 2 I W4 U2
pr1_mii0_rxd3 MII Receive Data bit 3 I V4 U1
pr1_mii0_rxdv MII Receive Data Valid I V7 T5
pr1_mii0_rxer MII Receive Data Error I U6 V3
pr1_mii0_rxlink MII Receive Link I V6 V2
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 65
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
