Appendix A: Specifications, Racking, and Cabling for the
V6000 and V6100
Hardware Appliance Diagrams 122
DSM Hardware Appliance Specifications 124
Space, Network, and Power Requirements 125
Appliance Rack Mount Safety Instructions 125
Rack Mounting the Appliance 126
Rack Mounting Instructions 128
Installing and Connecting Cables 133
This chapter provides the V6000/V6100 hardware appliance specifications and installation instructions.
Hardware Appliance Diagrams
Figure A-1: Front view of DSM hardware appliance with bezel :
WARNING
The DSM appliance is covered with three FIPS tamper evident stickers. Removing or
damaging the stickers voids FIPS compliance and the equipment warranty.
Figure A-2: Vormetric DSM hardware appliance with FIPS tamper evident stickers
